Aares Fusion Splicer
Aares Fusion Splicer
ATPL-999s Aares Fusion Splicer is a mini ber splicing equipment. Designed by the eld professional for the best performance and looks. Easy to carry & operate make it a perfect FTTx companion.
FAST 7 Sec Splice and 17 Sec heating time combined with a beautiful body design & colour improves user experience. Coupled with large capacity lithium battery guarantees a long time eld use of up to 220 splice. Conclusion is that the ATPL-999s is totally automatic small, light and beautiful optical ber fusion splicer. Backed by reliable service and support.
SPECIFICATIONS
FEATURE | COMPLIANCE |
Applicable Fibers | SM, MM, DS, NZDS |
Fiber Count | Single |
Fiber Diameter | Cladding diameter of 125μm, coating diameter of 250 ~ 900μm |
Splice Programs | Stored 40 Programs & 80 User-Congurable Options |
Average Splice Loss | 0.02dB(SM), 0.01dB(MM), 0.03dB(DS), 0.04dB(NZDS) |
Return Loss | More than 60dB |
Connecting Time | 7 Sec (Fast Mode) & 9 Sec (Typical) |
Splice Loss Evaluation | Yes |
Tensile Test | 2 Newton |
Screen | 4.3 inch. Color LCD Non Touch for Fast Response |
Optical Magnification | X / Y : 115 Times, X, or Y: 230 Times |
Power Supply Included | 11.1V lithium Battery, 13.5V/5A AC Adapter, 12V Car Power Supply |
Battery Usage | Typical Operating 220 (splice / heat shrink) on a Single Charge 3h |
Maximum Storage | Last 5000 Records |
Data Interface | USB2.0 |
Storage Conditions | COMPLIANCE |
Weight | SM, MM, DS, NZDS |
Size | Single |
Weather Protection | Cladding diameter of 125μm, coating diameter of 250 ~ 900μm |
STANDARD PACKAGE
DESCRIPTION | Quantity |
Optical Fiber Fusion Splicer | 1 Pc. |
AC Power Adapter | 1 Pc. |
Car Cigarette Lighter Charging Cable | 1 Pc. |
Fiber Cleaver | 1 Pc. |
Alcohol Dispenser | 1 Pc. |
Optical Fiber Holders | 6 Pc. |
Three Hole Stripper | 1 Pc. |
Spare Electrodes | 1 Pair |
Cooling Tray | 1 Pc. |
Carrying Case | 1 Pc. |
Screw Driver | 1 Set |
Combination Cutting Plier | 1 Pc. |
Protection Sleeve | 100 Pcs. |
Tissue | 1 Pkt. |
Patch Cord | 1 Pc. |
